UV MOB
Disinfection of rooms with UV-C
Fully automatic and secure mobile tower on wheels
DISINFECTION OF ROOMS FROM 12 TO 40M² IN A FEW MINUTES
This easily movable device is equipped with 4 UVC lamps and allows the treatment of rooms ranging from 10 to 40m². UVC rays are not channeled and they are spread throughout the room in all directions.
The equipment includes an automatic start-up and programmed shutdown. Security is ensured by an integrated presence detector which instantly cuts off the system in the event of human or animal presence. A wireless remote control warns of the end of the cycle and allows the appliance to be stopped at any time.
Optimum UVC energy level guaranteed
- Lamp life control thanks to the time counter.
People detection
- Delayed ignition allows you to leave the room quietly
- Automatic interruption in the event of an intrusion
Electronic exposure time management
- Germicidal treatment duration adjustable from 5 to 25 minutes
- Automatic shutdown.
Lamps protection
- In the event of accidental breakage of the lamp, a heat-shrunk sheath provides physical protection against any quartz dispersion.
Warning light box
- Wireless
- Verification of system start-up and end of cycle from outside the room
Easy to move
- Polyamide casters Standard EN12528.
Percentage of destruction of Microorganisms | |||||
Distance (m) |
Min. Energy (mW/m²) |
Duration (min) | Candida albicans yeast | Gram+ Bacteria Staphylococcus aurreus | Gram- Bacteria Escherichia coli |
2 m | 0.159 | 5 min | 99.77 % | 99.99 % | 99.99 % |
4 m | 0.055 | 10 min | 94.50 % | 99.98 % | 99.72 % |
UVC rays at 253.7 nm are germicidal.
PERMANENT DESTRUCTION OF MICRO-ORGANISMS IN SECONDS
Destroys: Viruses – Bacteria – Molds – Yeasts – Protozoa – Worms – Algae
- 230 V power supply
- 4 UVC lamps 41 W
- Lamps protected against breakage
- Height: 160 cm
- Width: 50 cm
- Length: 50 cm
- Weight: 12 kg
UV MOB BREATHE option
DISINFECTION OF AMBIANT AIR
In large rooms with people present, continuously and safely
The BREATHE option is a removable ventilation turbine designed for UV MOB
The BREATHE option is a convenient accessory for continuous air purification in the presence of personnel.
It comes in the form of a polycarbonate tube that shields against radiation and generates an airflow of 150m3/h: sufficient power to circulate purified air in a large room and reduce the viral load.
To use it, simply place the tube over the UV MOB lamps and connect the connector. Once the accessory is activated, the device no longer monitors presence and starts immediately.
The BREATHE option provides longer treatment durations compared to standard use of the UV MOB.
It is important to note that when the BREATHE option is activated, UV MOB cannot be used for surface disinfection.
Once this accessory is disconnected, UV MOB resumes its basic functionalities and can be used for surface disinfection.
If the tube is not removed, UVC radiation will not pass through the polycarbonate, and no disinfection will occur.
Reduction of Viral Load IN JUST MINUTES
